Rotabroach Magdrill 50mm Capacity

Rotabroach Element 50 1500w 50mm Magnetic Drill

The Element 50 is one of Rotabroach’s most versatile machines. Small in size, with reversible features to allow tapping. Suitable for drilling up to 50mm diameter by 50mm depth. The Elements use a dual motor protection system prolonging the machines life. Can be supplied as a non-tapping machine (on request).

Technical Data

Motor: 1500W.
No Load RPM: Low Gear: 100-265 RPM / High Gear: 200-500 RPM.
Max Hole Cutting Capacity: ø50 x 50mm Deep – 23mm with MT Shank Drill.
Overall Dimensions: Height: 460mm / Width: 195mm with Capstan / Length: 400mm with Guard.
Magnetic Adhesion: 13,500N.
Magnet Size: 200mm x 98mm.
Machine Weight: 15.8kg.

Safety Features

Cutsmart™ Technology / Fixed Guard / Magnetic Detection / Mechanical Clutch.
